1.Adjustable gluing rollers can coat glue smoothly on the paper surface.
2. The circulating glue system with temperature controller assures the adequate glue consistency.
3.A built-in washing system can clean thoroughly in 5 minutes
4.The convey belt with a suction system can ensure the paper can be sucked onto the convey belt without any movement.
| Model | FD-SJ600 | JS600 | JS720 | JS920 |
| Gluing width | 90-550mm | ≤600mm | ≤720mm | ≤920mm |
| Paper thickness | 100-200g/m2 | 100-300g/m2 | 100-300g/m2 | 100-300g/m2 |
| Feeding speed | 7-30pcs/min | 23m/min | 23m/min | 23m/min |
| Motor power | 8.25kw/380V 3P | 125w/220v 1phase | 125w/220v 1phase | 200w/220v 1phase |
| Machine weight | 600kg | 100kg | 130kg | 150kg |
| Machine dimension | 3700x1500x1200mm | 1020x500x440mm | 1120x500x440mm | 1380x820x620mm |
